ARUBA AP-535 (RW) UNIFIED AP

£1,435.04 excl. VAT

ARUBA AP-535 (RW) UNIFIED AP

Product code: JZ336A

ARUBA AP-535 (RW) UNIFIED AP

Product code Alt: JZ336A

Product Description

The Aruba 530 Series with 802.11ax (Wi-Fi 6), combined with Aruba intelligent software features are designed to deliver high performance connectivity in extreme density deployments of mobile and IoT devices.

The 530 Series is designed to simultaneously serve multiple clients and types of traffic, boosting overall network performance by up to 4X versus 802.11ac APs.

In addition to 802.11ax benefits, the 530 Series also provide Aruba differentiated capabilities that include AI-powered RF optimization, always-on connectivity and WPA3 certified security.

Additionally, Green AP mode for 802.11ax APs also leverages AI/ML capabilities for energy savings of up to 70%.

Enhanced performance
Aruba's ClientMatch feature intelligently groups Wi-Fi 6 clients onto the best AP's to leverage 802.11ax multi-user capabilities.

Smart power management
Aruba Intelligent Power Monitoring (IPM) allows APs to operate even if existing Ethernet switches lack adequate PoE power.

IoT and location ready
Leverage your Wi-Fi infrastructure to support Zigbee and Bluetooth use cases, devices and applications.

Specifications

Data transmission
Ethernet LAN data rates	100,1000,2500,5000 Mbit/s
Maximum data transfer rate	3550 Mbit/s
Performance
2.4 GHz	Yes
5 GHz	Yes
Auto MDI/MDI-X	Yes
Spread spectrum method	DSSS,OFDM
Networking standards	IEEE 802.11a,IEEE 802.11ac,IEEE 802.11ax,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n,IEEE 802.3af,IEEE 802.3at,IEEE 802.3bt,IEEE 802.3bz,IEEE 802.3z
Modulation	16-QAM,64-QAM,256-QAM,1024-QAM,BPSK,CCK,QPSK
Ethernet LAN data rates	100,1000,2500,5000 Mbit/s
Maximum data transfer rate	3550 Mbit/s
MIMO	Yes
Wireless LAN features
Modulation	16-QAM,64-QAM,256-QAM,1024-QAM,BPSK,CCK,QPSK
Network
Spread spectrum method	DSSS,OFDM
Networking standards	IEEE 802.11a,IEEE 802.11ac,IEEE 802.11ax,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n,IEEE 802.3af,IEEE 802.3at,IEEE 802.3bt,IEEE 802.3bz,IEEE 802.3z
Security
Cable lock slot	Yes
Security algorithms	WMM,WPA,WPA2
Features
2.4 GHz	Yes
5 GHz	Yes
Auto MDI/MDI-X	Yes
Spread spectrum method	DSSS,OFDM
Networking standards	IEEE 802.11a,IEEE 802.11ac,IEEE 802.11ax,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n,IEEE 802.3af,IEEE 802.3at,IEEE 802.3bt,IEEE 802.3bz,IEEE 802.3z
Modulation	16-QAM,64-QAM,256-QAM,1024-QAM,BPSK,CCK,QPSK
Ethernet LAN data rates	100,1000,2500,5000 Mbit/s
Maximum data transfer rate	3550 Mbit/s
MIMO	Yes
Maximum data transfer rate (2.4 GHz)	1148 Mbit/s
Maximum data transfer rate (5 GHz)	2402 Mbit/s
Ports & interfaces
USB connector type	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Power
Power consumption (max)	23.3 W
Power over Ethernet (PoE)	Yes
Design
Placement	Ceiling, Wall
Product colour	White
Cable lock slot	Yes
Cable lock slot type	Kensington
Antenna
Antenna type	Internal
Antennas quantity	4
Antenna gain level (max)	5.4 dBi
Antenna direction type	Omni-directional
Antenna features	Integrated antenna
Operational conditions
Operating relative humidity (H-H)	5 - 93%
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 93%
Weight & dimensions
Width	240 mm
Depth	240 mm
Weight	1.27 kg
Height	57 mm
