TP-Link TL-SF1005P network switch Unmanaged Fast Ethernet (10/100) Power over Ethernet (PoE) Black

Product code: TL-SF1005P
  • TP-Link TL-SF1005P
  • Unmanaged
  • Fast Ethernet (10/100)
  • Full duplex
  • Power over Ethernet (PoE)

TP-Link TL-SF1005P network switch Unmanaged Fast Ethernet (10/100) Power over Ethernet (PoE) Black

Product code Alt: TL-SF1005P
TP-Link TL-SF1005P network switch Unmanaged Fast Ethernet (10/100) Power over Ethernet (PoE) Black
  • Main image
  • Alternate product image
  • Alternate product image
  • Alternate product image
  • Alternate product image

Product Description

TL-SF1005P is a 5 10/100Mbps ports unmanaged switch that requires no configuration and provides 4 PoE (Power over Ethernet) ports. It can automatically detect and supply power with all IEEE 802.3af compliant Powered Devices (PDs). In this situation, the electrical power is transmitted along with data in one single cable allowing you to expand your network to where there are no power lines or outlets, where you wish to fix devices such as APs, IP Cameras or IP Phones, etc.

Power over Ethernet
4 of the 5 Auto-Negotiation RJ45 ports (Port 1 to Port 4) of the switch support Power over Ethernet (PoE) function. These PoE ports can automatically detect and supply power with those IEEE 802.3af compliant Powered Devices (PDs).

Overload Arrangement
TL-SF1005P has the priority function which will help protect the system when the system power is overloaded. If all PoE PDs power consumption is >= 58W, a priority will be arranged among the PoE ports, then the system will cut off the power of the lowest-priority port.

Port Priority Function
Priority (port-1=port-2=port-3>port-4): This function will help to ensure the normal operation of the system, it means Port 4 will be cut off when all total PoE PDs power consumption exceed 58W. For an example, Port 1, 2 and 4 is using 15.4W (maximum power for per port is 15.4W); the system power is 46.2W in total. If there is an additional PD inserted to Port 3 with 12W, and then the system will cut off the power of Port 4 because of the overloaded power, this means Port 1, 2 will use 15.4W, and Port3 will use 12W, no power will be supplied to Port 4.

Easy To Use
TL-SF1005P is easy to install and use. It requires no configuration and installation. With desktop design, outstanding performance and quality, the TP-Link’s TL-SF1005P 5-Port 10/100Mbps Desktop Switch with 4-Port PoE is an ideal choice for expanding your home or office network.

Features

  • 5 10/100Mbps RJ45 ports
  • With four PoE ports, transfers data and power on one single cable
  • Working with IEEE 802.3af compliant PDs, expands home and office network
  • Supports PoE Power up to 15.4W for each PoE port
  • Supports PoE Power up to 58W for all PoE ports
  • Requires no configuration and installation
    •

    Specifications

    Ports & interfaces
    Basic switching RJ-45 Ethernet ports quantity
    5
    Basic switching RJ-45 Ethernet ports type
    Fast Ethernet (10/100)
    Installed SFP modules quantity
    0
    Installed SFP+ modules quantity
    0
    Power
    Power supply included
    Yes
    Network
    Networking standards
    IEEE 802.3af, IEEE 802.3x
    10G support
    No
    Data transmission
    MAC address table
    2000 entries
    Switching capacity
    1 Gbit/s
    Management features
    Switch type
    Unmanaged
    Design
    Rack mounting
    No
    Power over Ethernet (PoE)
    Power over Ethernet (PoE)
    Yes
